Flow Switch With Weather Proof Enclosure A Flow Switch with Weather Proof Enclosure is designed for detecting flow or no-flow conditions of liquids in pipelines under hazardous area conditions. It operates using a paddle that actuates a micro switch when fluid flow reaches a preset velocity.
Ideal for chemical plants, oil & gas, and process industries, this flow switch offers robust performance, simple wiring, and long mechanical life, with SPDT contact outputs.
| Fluid | : | Liquids |
| Density / Sp. Gravity | : | Up to 2.95 |
| Viscosity | : | Up to 20 cp |
| Rated Temperature | : | Up to 90°C |
| Rated Pressure | : | Up to 17.5 Kg/cm² |
| Switch Rating | : | 125 VAC / 250 VAC, 5 Amp |
| Switching Output | : | SPDT (1 NO + 1 NC) |
| Flow Range | : | 15 to 1125 LPM of Water / Liquid |
| Line Size | : | 25 NB to 150 NB (Higher line size on request) |
| Available Materials | : | SS304 / SS316 / SS316L / Brass |
| Connection | : | 1″ BSP (M) / 1″ NPT (M) / Flange (Optional) |
| Enclosure | : | Weather Proof IP-65 / IP-66 |
